Description
Parameters
Engine Power 42.4kW
Engine Model Yanmar 4TNV98C
Engine Displacement 3.3L
Operating Weight 6T
Radiator 10.4L
Arm Digging Force 33kN
Standard Stick 1.7m
Standard Boom 3m
Carrier Wheel on Each Side 1
Thrust Wheel on Each Side 5
Hydraulic Tank 85L
Fuel Tank 130L
Bucket Capacity 0.21m³
Bucket Digging Force 45kN
Features
- Brand-new attachment operating system, preset various accessory pressure/flow parameters, realized adjustable auxiliary pipeline flow and controllable operation speed, and met frequent accessory replacement operation requirements for different customers and regions.
- Integrating intelligent technology into the products and developing a hierarchical password management system creates an innovative and secure working platform for customers and makes machine management more arbitrary and specific.
- With the application of an electronic control pump and a new main valve, the electronic control technology of the hydraulic pump adjusts power, the action response speed is faster, and the overall operation efficiency is improved.
- The newly-designed cab with much space and larger windows provides you with a wider view. Equipped with excellent sealing, the cab is free from dust, rain, and noise, which effectively reduces the fatigue of operator.
