Description
Parameters
Engine Power 145KW
Engine Model CUMMINS QSB6.7
Engine Displacement 6.7L
Operating Weight 27T
Radiator 40L
Arm Digging Force 130kN
Standard Stick 2.95m
Standard Boom 5.9m
Carrier Wheel on Each Side 2
Thrust Wheel on Each Side 9
Hydraulic Tank 277L
Fuel Tank 465L
Bucket Capacity 1.3m³
Bucket Digging Force 187kN
Features
- Powerful, robust and reliable powertrain & hydraulic components are applied for the most demanding applications. Selectable working modes match machine performance to the application, maximizing productivity.
- Through the accumulation of 15 years of experience and the “three-in-one” design and test system for large excavators of SANY, the operating life is more than 15,000H under mining working conditions.
- Anti-corrosion coating, Independent extra-large radiator, High-capacity Multi-stage Filtration System.
- Operation interface upgrade, intelligent operation interface of fashion technology, simpler and more convenient.
- Optimized positive flow hydraulics improve operating efficiency by up to 5% and fuel efficiency by up to 10%.
