Description
Dimensions
Platform Height Max. 4.5 m
Width 0.76 m
Wheel Base 1.06 m
Working Height Max. 6.5 m
Length Machine 1.47 m
Machine Height 1.99 m
Platform Dimension 1.3*0.72*1.21 m*m*m
Ground Clearance 60 mm
Platform Length 0.6 m
Performance
Lift Capacity 240 kg
Lift Capacity – Extension Deck Extended 120 kg
Drive Speed – Stowed/Raised 4/0.8 km/h
Turning Radius – Inside/Outside 0.4/1.6 m
Lifting Motor 1.3 kW
Gradeability 25 %
Tilt Sensor Activation (Side/Front) 1.5/3 °
Tires 250*80 mm
Power
Charger (Input) AC100-240 V
Battery 2*12/115 V/Ah
Drive Motor DC24 V
Others
Weight 945 kg
