Description
Number of configuration 4 standard and 8 optional operation devices
Clean water tank volume Maximum volume: 13.9 m³
Water pump flow 1000 L/min
Watering width ≥14 m
Range of high-pressure water gun(rear ) ≥38 m
Cleaning speed 3-25 km/h
Rated speed 1450 r/min
Flushing width (duckbill) ≥8 m
Flushing width(converging flushing) ≥24 m
Vehicle parameters
Announced model SYR5125GSSDF6
Chassis model EQ1125SJ8CDC/DFAC
Engine power 115/Quanchai Q28-156E60 kw
Transmission model 6TS55/LY
Curb mass 11995 Kg
Curb weight 4930 kg
Overall dimensions (LxWxH) 7220x2350x2500 mm
Wheelbase 3800 mm
Complete Configuration, Comprehensive Functions
· 4 standard operation devices and 8 optional operation devices to meet the needs of more operation scenarios
Ultra-Light Chassis, Super-Large Volume
· The curb mass is 3% lower than that of competitive products, the maximum total volume of water tank is 13.9m³, and the continuous sprinkling operation time of single tank is leading in the industry
Optimal Selection of Suppliers with Excellent Quality
· Qiaonan nozzle, water cannon, WLOONG water pump, EAST ball valve and STNC pneumatic valve groups are all selected with first-class quality and reliable performance
