Description
Country Standard
Power Frequency 50 HZ
Power Voltage 380(±10%) V
Working Speed
The Power of Trolleying Mechanism 4.0 kW
The Speed of Trolleying Mechanism 0~60 m/min
The Power of Slewing Mechanism 2×4.0 kW
The Speed of Slewing Mechanism 0~0.6 r/min
The Power of Hoisting Mechanism 30 kW
The Speed of Hoisting Mechanism 0-90 m/min
Operation
Tip Load at Max. Jib Length 1.6 T
Max. Height Under Hook 222m/224m/222.3m m
Max. Jib Length 60 m
Max. Lifting Moment 125 t·m
Max. Lifting Capacity 8 T
Free Standing Height 45m/49m/51.5m m
Strong
· Superior performance
Safe
· Tower group anti-collision technology
Intelligent
· Distributed control system
Economical
· The crane boom has a long service life due to its steel structure.
