Description
Automatic/Manual Automatic
Axle –
Capacity (Struck/Heaped) 60/78 m³
Displacement 16.72 L
Engine Model Weichai WP17
Gearbox Type –
Left/Right Hand Drive Left/Right
Load Weight 136 T
Lubrication System Automatic lubrication system
Max. Gradeability 30 %
Maximum Torque 3000 NM
Min. Turning Radius 13200 mm
Net Weight 105 T
Number/Type of Cylinders 8/V shape,turbocharged
Size 11812*7723*6184 mm
Total Power ≥1400 kW
Tyre 33.00R51
Steering
· Independent hydraulic steering with closed-center steering valve, pressure compensating piston pump and accumulator. The accumulator provides uniform steering regardless of engine speed. In the event of loss of engine power, it provides emergency power to the system for steering.
Electric Drive System
· The performance of drive system depends on the gross vehicle weight, gradient and length of transport road, rolling resistance, engine power, and other parameters. The drive system can adjust to the actual working conditions to realize the optimal performance of the mining dump truck.
Please contact us for Brochure and more Informations about our Mining Truck.
